LOCKWOOD BATWING SINGLE FIRE DOOR SEAL SET STANDARD
Description
BATWING SEAL DOOR SET 12MMX12MM - SINGLE DOOR STD BLACK
Lorient Batwing® Acoustic Smoke Seal
The Lorient Batwing® series is primarily designed to contain sound and restrict the spread of medium temperature smoke around hinged door assemblies. Their symmetrical design and unique curved sealing fins provide outstanding performance benefits.
Our newly launched clear Lorient Batwing® is also available for that ultra discreet look. (Note: Clear does not restrict light penetration).
Features
Seals restrict the spread of medium temperature smoke (200°C)
Highly effective acoustic seal that can be retrofitted to existing door assemblies
Low friction curved elastomeric fins spring back to original shape to provide continuous performance
Discreetly positioned in frame rebate to provide a fully concealed sealing solution
Simple peel-and-stick installation, our aggressive self-adhesive backing is tested on many surfaced to ensure seal longevity
Co-extruded rigid back PVC with flexible fins
Suits head and jambs of single and double leaf doors
Single doorset (SDS)
Standard length
Aggressive film backed self-adhesive fixing
Gap size 2mm to 3mm
Supplied in trade pack
Approvals
Fire: Tested in accordance with AS1530.4 on proprietary AS1905.1 fire door assemblies for up to 4 hour rating.
Smoke: AS1530.7 smoke test data on AS6905 compliant smoke door assemblies.
Sound: Acoustically tested in accordance with ISO10140-2 and AS/NZS717.1 with ratings up to 39Rw on appropriate rated assemblies.
Durability: Long term mechanical test, completing 1,000,000 cycles without failure.
Track Lengths Included
1 at 1.0m
2 at 2.1m
Finish
Black
